    Servo Energy-Saving Pet Preform Injection Molding Machine

    PET Dedicated Screw System Large Shot Capacity High-Response Servo Drive

    Significantly increases the melting speed and injection volume

    Reduces the plasticizing temperature

    Effectively improves the shrinkage of the preform and enhances transparency

    Increase the thimble force and ejection stroke

    More suitable for deep cavity PET preform molding

    High response and high precision

    The diving system of servo energy-saving injection molding machines responds sensitively and quickly

    Only needs 0.05 seconds to reach the maximum output value

    Maximizes production efficiency

    Get a Free Quote

    Product Parameters

    Category Item Unit IJT-SV530-PET
    Injection Unit Screw Diameter mm 85 / 90
    Screw L/D Ratio L/D 24.6 / 24.2
    Shot Volume cm³ 2614 / 2931
    Injection Weight (PET) g 3136 / 3517
    Injection Pressure MPa 139 / 124
    Injection Rate cm³/s 675 / 678
    Injection Speed mm/s 110
    Plasticizing Capacity g/s 169 / 140
    Screw Speed rpm 0 ~ 175
    Clamping Unit Clamp Tonnage kN 5300
    Toggle Stroke mm 850
    Space Between Tie-Bars mm 840 × 830
    Max. Mold Height mm 850
    Min. Mold Height mm 350
    Ejector Stroke mm 220
    Ejector Tonnage kN 158
    Ejector Number Piece 13
    Others Max. Pump Pressure MPa 14
    Motor Power kW 22 + 36
    Heater Power kW 55
    Machine Dimension (L×W×H) m 9.1 × 2.2 × 2.5
    Machine Weight ton 22.5
    Oil Tank Capacity L 1100

    Product Details
